Selecting the Trailer Brake Type
Use the instrument cluster display controls
on the steering wheel to select the correct
setting for your trailer.
Note: Select Default
Electric/Surge/None if the trailer has
electric, surge or no brakes.
Selecting the Trailer Brake Effort
Select the correct setting for your trailer.
Note: Select a different setting if your
trailer's brakes require more initial voltage,
or you prefer more aggressive trailer braking.
INTEGRATED TRAILER BRAKE CONTROLLER –
TROUBLESHOOTING
INTEGRATED TRAILER BRAKE CONTROLLER – INFORMATION
MESSAGES
ActionMessage
The system detects a correct trailer
connection during a given ignition cycle.
Trailer Connected
The system detects the trailer wiring
connection is disconnected, during a given
ignition cycle.
Trailer Disconnected
The system detects an electrical fault in
the trailer brake circuit. If this message
appears without a trailer attached, see your
authorized dealer. If a trailer is attached,
inspect and repair the trailer wiring.
Trailer Wiring Fault
Displays the current gain setting for the
trailer brake.
Trailer Brake Gain: {trailer gain value:#0.0}
Displays the current gain setting for the
trailer brake when you do not have a trailer
connected.
Trailer Brake Gain: {trailer gain value:#0.0}
No Trailer
336
2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing
Integrated Trailer Brake Controller (If Equipped)
