Ford F53 User Manual

FUSE SPECIFICATION CHART
F53 Power Distribution Box
WARNINGS
Always disconnect the battery before
servicing high current fuses.
To reduce risk of electrical shock,
always replace the cover to the
power distribution box before
reconnecting the battery or refilling fluid
reservoirs.
Locate the power distribution box in the
engine compartment. It has high-current
fuses that protect your vehicle's main
electrical systems from overloads.
If the battery has been disconnected and
reconnected, you will need to reset some
features. See Changing the 12V Battery
(page 101).
E161519
68
Motorhome (TY3) Canada/United States of America, enUSA, Edition date: 201712, Second Printing
Fuses

Ford F53 Specifications

General

Fuel Type	Gasoline
Engine	7.3L V8
Horsepower	350 hp
Torque	468 lb-ft
Transmission	6-speed automatic
Wheelbase	158", 178", 190", 208", 228", 242" (depending on chassis)
Brakes	4-wheel disc
Rear Suspension	Tapered multileaf springs; heavy-duty gas shock absorbers; stabilizer bar
