Protected ComponentsFuse RatingFuse or Relay
Number
Blower motor relay coil.15A7
Brake lamps feed.10A8
Trailer brake control module
Not used.—9
Instrument cluster memory.10A10
Wiper/washer module.30A11
Wiper feed.
Not used.—12
Anti-lock brake system module –
HydroMax.
10A13
Anti-lock brake system module – Hydro-
boost.
10A14
Instrument cluster run/start.
Left-hand direction indicator feed.15A15
Body builder battery (+12V) feed.20A16
Body builder radio feed.5A17
Not used.—18
Daytime running lamps relays.5A19
Not used.—20
Right-hand direction indicator feed.15A21
Trailer tow direction indicators.20A22
Cluster run/accessory.10A23
Not used.—24
Body builder right-hand low beam head-
lamp feed.
10A25
Not used.—26
Not used.—27
Not used.—28
Not used.—29
82
Motorhome (TY3) Canada/United States of America, enUSA, Edition date: 201712, Second Printing
Fuses
