Protected ComponentsFuse RatingFuse or Relay
Number
Anti-lock brake system module –
HydroMax.
60A
2
16
Anti-lock brake system module – Hydro-
boost.
40A
2
Horn feed.
20A
2
17
Backup lamp relay coil.
20A
2
18
A/C clutch coil.
A/C demand switch.
Brake on/off switch.
20A
2
19
Multifunction switch.
Powertrain control module relay (Power
distribution box fuses # 3, 5, 7, 18).
30A
2
20
Fuel injectors.
20A
2
21
Fuel pump motor.
Mass air flow sensor.
Powertrain control module.
Cigar lighter feed.
20A
2
22
Diagnostic tool connector.
Blower motor feed.
40A
2
23
Instrument panel battery feed (fuses #4,
10, 16, 22).
50A
2
24
Ignition switch feed (Instrument panel
fuses #1, 5, 7, 11, 13, 14, 17, 19, 23, 36; Power
distribution box fuses #9, 11).
40A
2
25
Fuse holder #2.
Ignition switch feed (Instrument panel
fuses #5, 11, 17, 23, 38).
40A
2
26
Headlamps.
30A
2
27
Daytime running lamps on/off relay coil.
Headlamp daytime running lamp relay
feed.
High beam headlamps flash to pass.
(Instrument panel fuses #25, 31).
Starter relay feed.
30A
2
28
70
