Protected ComponentsFuse RatingFuse or Relay
Number
Starter motor solenoid.
Power brake assist motor – HydroMax.
60A
2
29
Fuse holder #1.
Anti-lock brake system module – Hydro-
boost.
40A
2
A/C clutch relay.—R1
Fuel pump relay.—R2
Horn relay.—R3
Starter relay.—R4
Blower motor relay.—R5
Powertrain control module relay.—R6
Fuel pump diode.—Diode 1
Air conditioning clutch diode.—Diode 2
1
Mini fuse.
2
Maxi fuse.
71
Motorhome (TY3) Canada/United States of America, enUSA, Edition date: 201712, Second Printing
Fuses
