Protected ComponentsFuse RatingFuse or Relay
Number
Headlamp daytime running lamp relay
feed.
High beam headlamps flash to pass.
(Instrument panel fuses #25, 31).
Ignition switch feeds (instrument panel
fuses #F26).
40A
2
J6
Instrument panel fuses #F24, F22, F20,
F26, F21, F8, F6, F4, F2.
40A
2
J7
Power distribution box fuses M4, M1-4.
Instrument panel fuses F11, F13, F15, F17.
50A
2
J8
Starter relay feed.
30A
2
J9
Starter motor solenoid.
Power distribution box fuse M1-1.
60A
2
J10
Power brake assist motor (HydroMax).
Trailer tow electronic brake.
30A
2
J11
Lighting primary.
60A
2
J12
Power distribution box fuse M1-2.
Instrument panel fuses #F19, F5, F3.
Brake on/off.
20A
2
J13
Hazard.
Horn.
20A
2
J14
HydroMax anti-lock brake system module.
60A
2
J15
Trailer tow parking lamps.
20A
2
J16
1
Mini fuse.
2
J case fuse.
Diode and Relay Module
Locate the module box with the power
distribution box in from of the radiator.
79
