4. Install all of the lug nuts and partially
tighten them in the sequence shown.
5. Lower your vehicle and remove the
vehicle jack.
6. Fully tighten all of the lug nuts in the
sequence shown. See Technical
Specifications (page 141).
7. Install the wheel trim.
WARNING
Have the lug nuts checked for
tightness and the tire pressure
checked as soon as possible.
TECHNICAL SPECIFICATIONS
Wheel Lug Nut Torque
NmWheel Type
135 NmAll
Tire Pressures (Cold Tires)
Up to 50mph (80km/h)
FullNormalVehicle Load
RearFrontRearFrontTire Position
barbarbarbarTire SizeVariant
3.23.23.23.2175/65 R14-TTemporary spare wheel
when it differs from the
other fitted wheels
141
Fiesta (CC3) Vehicles Built From: 14-07-2014, Australia, enAUS
Wheels and Tires
