5. Install the air cleaner assembly lid and

tighten the four fasteners.

DRIVE BELT ROUTING - 1.0L

ECOBOOST™

E163197

DRIVE BELT ROUTING - 2.0L

E189146

236

Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing
