FORD GT GT3 | USER MANUAL
Dash Pages
The dash display in this car is non-adjustable and features a single page to
display critical vehicle information.
DASH CONFIGURATION
METER TOP LEFT Graphical depiction of engine RPM
NUMBER TOP RIGHT Road speed (km/h or mph)
NUMBER MID-LEFT Engine water temperature (°C or °F)
LARGE NUMBER CENTER Currently selected gear
NUMBER MID-RIGHT Engine oil pressure (kPa or psi)
BOTTOM RIGHT Engine RPM
PIT LIMITER
When the pit limiter is active all LED’s in the shift light cluster will flash on and off.
SHIFT LIGHTS
2 GREEN 6750 rpm
4 GREEN 7000 rpm
6 GREEN 7250 rpm
2 RED 7500 rpm
FORD GT GT3 | DASH PAGES
