2
QUICK START
DASHBOARD (RIGHT-HAND DRIVE)
The presence and position of controls, instruments and gauges may vary depending on the versions.
1. Side air vent – 2. Passenger side air bag – 3. Central air vents – 4. Oddment/Car radio compartment – 5. Left steering column
stalk: external lights – 6. Instrument panel and warning lights – 7. Right steering column stalk: windscreen wiper, washer, trip
computer controls – 8. Driver side air bag – 9. Control plate – 10. Power windows controls – 11. Gear lever –
12. Heating/ventilation/climate control – 13. Oddment compartment
KA00178m
603.95.157 PP KA EN 1ed trip 15-10-2010 13:49 Pagina 2
