Ford Ka - Seats

26
SAFETY
STARTING
AND DRIVING
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
SERVICING
AND CARE
TECHNICAL
SPECIFICATIONS
INDEX
KNOWING
YOUR CAR
Backrest angle adjustment fig. 18
Turn knob B.
Seat height adjustment
(where provided) fig. 19
Operating lever C it is possible to lift
or lower the rear area of the cushion
to achieve the most comfortable driving
position.
Backrest tilting fig. 20
To tilt the seat, operate lever D
(movement a) and push the backrest
forward to lock (movement b); release
lever D and push the backrest to slide
the seat forward (movement c, applies
only to seats with easy entry).
SEATS
FRONT SEATS
fig. 17
A
E
KA00006m
fig. 18
B
KA00007m
Horizontal adjustment fig. 17
Lift lever A and push the seat forwards
and backwards.
All adjustments must
be made with the car
stationary.
WARNING
Once you have released
the adjustment lever,
always check that the seat is locked
on the guides by trying to move
it back and forth. Failure to lock
the seat in place could result in
the seat moving suddenly and
the driver losing control of the car.
WARNING
fig. 19
C
KA00008m
fig. 20
2
3
4
6
5
1
D D
KA00018m
Seat heating, fig. 17
(where provided)
Press the button E to switch
the function on/off.
IMPORTANT If this function
is activated with engine off the battery
will run down.
