Ford Mustang 2017 User Manual

Protected componentsFuse amp ratingFuse or relay number
Run-start bus.30A34
Restraints control module.5A35
Auxiliary body module.15A36
Power distribution box run-start bus.20A37
Not used (spare).30A—
CHANGING A FUSE
Fuses
WARNING
Always replace a fuse with one that
has the specified amperage rating.
Using a fuse with a higher amperage
rating can cause severe wire damage and
could start a fire.
E217331
If electrical components in the vehicle are
not working, a fuse may have blown. Blown
fuses are identified by a broken wire within
the fuse. Check the appropriate fuses
before replacing any electrical
components.
150
Mustang (CZG, CZY) Vehicles Built From: 02-05-2016, HR3J 19A321 AKA enGBR, First Printing
Fuses
