Fuse/relay
location
Fuse amp
rating
Passenger compartment fuse panel
description
18 15A Parklamps, PWM (backlighting), Autolamps
19 10A Heated mirrors, Rear defrost switch indicator
20 10A Restraints (air bag module/OCS module)
21 15A Transmission range sensor (transmission
position switch)
22 15A
Front washer pump, Electrochromatic mirror,
Compass, Cluster (RUN/ACC), Integrated
Control Panel (ICP) logic, Rear wiper (wagon
only), Rear washer (wagon only)
23 30A Front wiper motor
24 — Not used
25 20A Power point
26 20A Power locks, Liftgate (wagon)/Trunk (sedan)
release
27 10A Anti-lock Brake System (ABS), Speed
control, Traction control, Brake-shift
interlock, A/C function switch (manual A/C
only), Temperature blend door (manual A/C
only), Defrost coil
28 15A Turn signals, Back-up lamps
29 20A Cigar lighter
30 10A Courtesy lighting, Battery saver, Power
mirrors, Decklid lamp, Power antenna
(wagon only), Pulse stretching module
(wagon only), Glove box lamp
31 10A Blower motor relay coil, Puddle lamp relay
coil, Electronic Automatic Temperature
Control (EATC) logic
32 10A Cluster, Flex fuel module, ICP logic, Passive
anti-theft module (GEM power)
33 15A Hazard flasher, Cluster power, ICP power,
EATC
34 5A GEM logic
35 10A Backlighting, Ashtray light
36 2A Powertrain Control Module (PCM) relay,
Fuel pump relay, A/C clutch
REVIEW COPY
2005 Taurus (tau), Owners Guide (post-2002-fmt) (own2002),
Market: USA_English (fus)
Roadside Emergencies
178
