Protected componentsFuse amp ratingFuse or relay number
Not used.-56
Left-hand high intensity discharge head-
lamp.
20A
*
57
Alternator A-line.
10A
*
58
Brake on/off switch.
10A
*
59
Not used.-60
Not used.-61
A/C clutch relay.
10A
*
62
Not used.-63
Massage control seats.
15A
*
64
Fuel pump relay.
30A
*
65
Fuel injectors.
Powertrain control module relay.Relay66
Oxygen sensor heater.
20A
*
67
Mass airflow sensor.
Variable camshaft timing solenoid valve.
Canister vent solenoid.
Canister purge solenoid.
Ignition coils.
20A
*
68
Vehicle power 1 (powertrain control
module).
20A
*
69
A/C clutch.
15A
*
70
Fan control relay coils 1-3.
Variable air conditioning compressor.
Auxiliary transmission warmup.
Turbo charge waste-gate control.
Electronic compressor bypass valve.
All-wheel drive module.
Positive crankcase ventilation heater.
Not used.-71
Not used.-72
Not used.-73
227
Taurus (CPH) Canada/United States of America, enUSA, First Printing
Fuses
