Protected componentsFuse amp ratingFuse or relay number
Wiper relay.Relay55
Not used.-56
Left-hand high intensity discharge head-
lamp.
20A
1
57
Alternator A-line.
10A
1
58
Brake on/off switch.
10A
1
59
Not used.-60
Not used.-61
A/C clutch relay.
10A
1
62
Not used.-63
Massage control seats.
15A
1
64
Fuel pump relay.
30A
1
65
Fuel injectors.
Powertrain control module relay.Relay66
Oxygen sensor heater.
20A
1
67
Mass airflow sensor.
Variable camshaft timing solenoid valve.
Canister vent solenoid.
Canister purge solenoid.
Ignition coils.
20A
1
68
Vehicle power 1 (powertrain control
module).
20A
1
69
A/C clutch.
15A
1
70
Fan control relay coils 1-3.
Variable air conditioning compressor.
Auxiliary transmission warmup.
Turbo charge waste-gate control.
Electronic compressor bypass valve.
All-wheel drive module.
Positive crankcase ventilation heater.
Not used.-71
229
Taurus (CPH) Canada/United States of America, enUSA, First Printing
Fuses
