Protected componentsFuse amp ratingFuse or relay number
Left front and right rear smart window
motors.
30A1
Driver seat switch.15A2
Right front smart window motor.30A3
Demand lamps battery saver relay.10A4
Audio amplifier.20A5
Not used (spare).5A6
Driver seat module logic.7.5A7
Left front door zone module.
Keypad.
Not used (spare).10A8
SYNC module.10A9
Multi-function displays.
Electronic finish panel.
Radio frequency transceiver module.
Run accessory relay.10A10
Intelligent access module logic.10A11
Heads-up display.
Puddle lamp.15A12
Backlighting LED.
Interior lighting.
Right-hand direction indicators.15A13
Left-hand direction indicators.15A14
Stop lamp.15A15
Backup lamp.
Right front low beam.10A16
Left front low beam.10A17
Start button.10A18
Keypad illumination.
Brake-shift interlock.
Powertrain control module wake-up.
Immobilizer transceiver module.
232
Taurus (CPH) Canada/United States of America, enUSA, First Printing
Fuses
