2. Locate the yellow cap at the end of the
clear tube.
3. Using the yellow cap tool, press the tab
located on the kit compressor housing
while pulling up on the sealant canister.
Installation of the sealant canister to
the kit
1. Align the sealant canister with the kit
housing.
2. Once aligned, seat the sealant canister
by lightly pushing down until you hear
an audible click.
3. Wrap the clear tube around the
compressor housing.
Note: If you experience any difficulties with
the removal or installation of the sealant
canister, consult your authorized Ford dealer
for assistance.
272
Taurus (CPH) Canada/United States of America, enUSA, First Printing
Wheels and Tires
