Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
29 30A** Rear defroster
30 — Not used
31 40A** Convertible top motor
32 30A** SSP2
Relay 001 Full ISO SSP1
Relay 002 Full ISO SSP4
Relay 003 Full ISO Rear defroster
Relay 004 Full ISO SSP3
Relay 005 Full ISO SSP2
Relay 006 — Not used
Relay 007 1/2 ISO Fuel pump
Diode 01 — Not used
Diode 02 1A Fuel pump relay coil
*Mini fuses **Cartridge fuses
JUMP STARTING YOUR VEHICLE
The gases around the battery can explode if exposed to flames,
sparks, or lit cigarettes. An explosion could result in injury or
vehicle damage.
Batteries contain sulfuric acid which can burn skin, eyes and
clothing, if contacted.
Do not attempt to push-start your vehicle. Automatic
transmissions do not have push-start capability; doing so may
damage the catalytic converter.
Preparing your vehicle
Your battery is located in the trunk of your vehicle. See Lockable and
electronic trunk remote control in the Driver Controls chapter for
instructions on opening the trunk with a dead battery.
When the battery is disconnected or a new battery is installed, the
transmission must relearn its shift strategy. As a result, the transmission
2005 Thunderbird (tbr)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
162
