Vehicle overviews
Fr
ont view
Fig. 1 Overview of the front of the vehicle.
1
Door handles ................................................................................................................................... 82
2
Tank flap ........................................................................................................................................... 282
3
Headlamps ...................................................................................................................................... 295
4
Sensors for assist systems ........................................................................................................ 363
5
Fog lamps ........................................................................................................................................ 295
6
Radar sensor for assist systems ............................................................................................. 363
7
Behind a cover: mounting for towing eye ............................................................................ 307
8
Lever for opening the bonnet ................................................................................................... 314
9
Windscreen:
— with vehicle identification number .................................................................................... 404
— with windscreen heating ........................................................................................................ 126
— with windscreen wiper ............................................................................................................ 114
— with camera window for assist systems ......................................................................... 363
— with rain/light sensor positioned near the interior mirror .........................................
116,
36
3
