INSTALLATION PROCEDURE / STEP 8 / STEP 9 / STEP 10
- 6 -
8
Use 1 1/2" pan head screws to anchor
wall bumper and bumper guide into
center hole on each side.
INSTALLATION PROCEDURE / STEP 11
11
Install outer door panel by lifting up & into top track (1)
(Do not lift by towel bar, be careful not to bump
panel against metal track.)
9
Measure opening at top of wall jamb,
cut top track (1) 1/16" shorter than opening.
10
Place top track down over wall jambs as
shown.
1 1/2" PAN HEAD SCREW
