Work Bench Fitting
FM5, FM8 & FM10 (All Versions) 31
6 min.
Ensure that there is a minimum of a 6mm gap
between the top of the ram cross piece and
the bottom of the rectangular tube on the tray
underside.
3) Insert the corner posts into
the sockets in the tray.
4) Slot the pins on the mesh
panels into the corner posts.
NO LOGS
NO LOGS
Do not place any logs or leave
any split logs in the shaded
regions shown opposite.
If logs are left in these
areas then damage may be
caused to the work bench as
subsequent logs are split.
