Formula Linea - Mounting Tubeless Tires

11
2.2 Mounting TUBELESS tires
-Install the wheel, preferably on a
frame or truing stand to center the
wheels. Clean the inside of the rim
with a cloth dampened with alcohol
in order to degrease the channel in-
side the rim.
CAUTION: Use only alcohol to
clean the rim, other products
may damage the rim.
-Start installing the tape (1) for the
TUBELESS kit, starting the tape
halfway between 2 nipple holes (2).
-Keeping the tape tight (1) turn the
wheel while installing the tape. (3)
Make sure the tape stays in the
middle of the rim channel. The tape
should make two complete rota-
tions around the rim so that each
part of the rim is covered by two
layers of tape. Check the tape to
make sure it is fastened to the rim
at all points.
-Cut the tape (1).
-Make sure the tape is in the middle
of the rim channel and not protrud-
ing (2).
-Use a sharp punch slightly smaller
in diameter than the valve to make a
hole (4) in the tape where the valve
hole is found in the rim.
-Remove the valve cap (9) and valve
nut (6).
-Insert the valve (5) bringing it
against the rim channel. Tighten the
valve nut (6) from the opposite side
as shown in the figure. The valve nut
should only be tightened by hand.
2 3
1
2
4
5
6
5
6
9
5
6
