17
-Put the partly inflated Presta valve tube (21) in the tire.
-Insert the bead (18) of the tire into
the rim groove starting from the
point opposite the valve. Continue
around the entire rim circumfer-
ence being careful not to pinch the
inner tube.
-Inflate the inner tube until the two
tire beads go into the correct po-
sition.
WARNING: Even when using an inner tube, it is EXTREMELY important for
safety purposes to seat the two tire beads to prevent the tire from coming
off the rim.
5.4 Transport and storage
When the wheel is transported separately from the bike or when it is not used for an
extended period, put it in a wheel bag to protect it from impact, dust and dirt.
21
18
18
