13
1.5 CTS (COMPRESSION TUNING SYSTEM) REPLACEMENT:
ATTENTION: FORMULA is not responsible for
any damage to parts of the shock absorber
due to this operation and/or to people. Contact a
specialized mechanic. Strictly follow this proced-
ure. Failure to comply can cause suspension mal-
functions and cause DAMAGE AND DEATH.
ATTENTION: Use the ONLY FORMULA suspension
pump for this operation.
Follow the entire procedure shows on the For-
mula website or Formula’s Youtube channel.
1.6 SPRING REPLACEMENT:
ATTENTION: FORMULA declines all responsibility for the use of a different spring to
the FORMULA one, suitably designed and tested with our products.
The procedure for replacing the coil spring on the rear shock absorber is as fol-
lows:
1) Remove the shock from the frame;
2) Unscrew the spring preload ring nut COUNTERCLOCKWISE (figure O) until the spring
is free to move (figure P);
Fig. O Fig. P
