17
• Pull down the group with bumper, washer and spacer against the spring ring;
• Pull down the spring against the spring ring and apply the correct spring preload;
End procedure
1.9 PROBLEMS - CAUSES – REMEDIES:
This paragraph reports some problems that may occur when using the shock, their
possible causes and remedy.
ATTENTION: The operations listed below and accompanied by this symbol must
be performed exclusively by Authorized Service Centers.
Following a jump, the
rear hurls me forward
Rebound too excessive Turn CLOCKWISE the re-
bound adjuster by 1 or 2
clicks
The spring is free to ro-
tate axially around the
shock
Preload below the mini-
mum allowed
Turn CLOCKWISE the thre-
aded ring
The shock absorber has
little sensitivity and is
very supported on the
back, the bike is too un-
balanced on the front
Spring too preloaded or
compression too high
Turn the threaded ring
counterclockwise. Or turn
the CTS compression regi-
ster counterclockwise by 1
or 2 clicks
