- 132 -
Level 4
Command Mode
Global Config
7.2.11.7 switchport unicast packet-rate
This command will protect your network from unicast storms by setting a threshold level for unicast traffic
on each port.
Syntax
switchport unicast packet-rate {1 | 2 | 3 | 4}
1 - Threshold level represents 64 pps for 1G Port or 1042 pps for 10G port.
2 - Threshold level represents 128 pps for 1G Port or 2084 pps for 10G port.
3 - Threshold level represents 256 pps for 1G Port or 3124 pps for 10G port.
4 - Threshold level represents 512 pps for 1G Port or 4167 pps for 10G port.
Note: pps (packet per second)
Default Setting
Level 4
Command Mode
Interface Config
This command will protect your network from unicast storms by setting a threshold level for unicast traffic
on all ports.
Syntax
switchport unicast all packet-rate {1 | 2 | 3 | 4}
1 - Threshold level represents 64 pps for 1G Port or 1042 pps for 10G port.
2 - Threshold level represents 128 pps for 1G Port or 2084 pps for 10G port.
3 - Threshold level represents 256 pps for 1G Port or 3124 pps for 10G port.
4 - Threshold level represents 512 pps for 1G Port or 4167 pps for 10G port.
all - This command represents all interfaces.
Note: pps (packet per second)
