mirror <slot/port>
<slot/port> - Interface Number.
Default Setting
None
Command Mode
Policy-Class-Map Config
Incompatibilities
Drop, Redirect
7.21.3.4 redirect
This command specifies that all incoming packets for the associated traffic stream are redirected to a
specific egress interface (physical port or port-channel).
Syntax
redirect <slot/port>
Command Mode
Policy-Class-Map Config
Incompatibilities
Drop, Mirror
7.21.3.5 conform-color
This command is used to enable color-aware traffic policing and define the conform-color class maps
used. Used in conjunction with the police command where the fields for the conform level (for simple,
single-rate, and two-rate policing) are specified. The <class-map-name> parameter is the name of an
existing Diffserv class map, where different ones must be used for the conform and exceed colors.
Syntax
conform-color <class-map-name>
<class-map-name> - Name of an existing Diffserv class map, where different ones must be used for
the conform colors.
