Fortinet FortiGate 110C User Manual

NAT/Route Mode
Port IP: ____.____.____.____
Netmask: ____.____.____.____
Port IP: ____.____.____.____
Netmask: ____.____.____.____
Port IP: ____.____.____.____
Netmask: ____.____.____.____
Port IP: ____.____.____.____
Netmask: ____.____.____.____
Port IP: ____.____.____.____
Netmask: ____.____.____.____
The internal interface IP address and netmask must be valid for the internal network.
Transparent mode
Management IP: IP: ____.____.____.____
Netmask: ____.____.____.____
The management IP address and netmask must be valid for the network from which you will
manage the FortiGate unit.
General settings
Administrator password:
Network Settings: Default Gateway: ____.____.____.____
Primary DNS Server: ____.____.____.____
Secondary DNS Server: ____.____.____.____
A default gateway is required for the FortiGate unit to route connections to the Internet.
Factory default settings
NAT/Route mode Transparent mode
Port 1 interface 192.168.1.99 Management IP 0.0.0.0
WAN1 interface 192.168.100.99 Administrative account settings
WAN2 interface 0.0.0.0 User name admin
Password (none)
To reset the FortiGate unit to the factory defaults, in the CLI type the command
execute factory reset
Web-based Manager
1. Connect the FortiGate internal interface to a management computer Ethernet interface.
Use a cross-over Ethernet cable to connect the devices directly. Use straight-through
Ethernet cables to connect the devices through a hub or switch.
2. Congurethemanagementcomputertobeonthesamesubnetastheinternalinterface
of the FortiGate unit. To do this, change the IP address of the management computer to
192.168.1.2 and the netmask to 255.255.255.0.
3. To access the FortiGate web-based manager, start Internet Explorer and browse to
https://192.168.1.99 (remember to include the “s” in https://).
4. TypeadminintheNameeldandselectLogin.
NAT/Route mode
To change the administrator password
1. Go to System > Admin > Administrators.
2. Select Change Password for the admin administrator and enter a new password.
To congure interfaces
1. Go to System > Network > Interface.
2. Selecttheediticonforeachinterfacetocongure.
3. Set the addressing mode for the interface. (See the online help for information.)
• For manual addressing, enter the IP address and netmask for the interface.
• For DHCP addressing, select DHCP and any required settings.
• For PPPoE addressing, select PPPoE, and enter the username and password and
any other required settings.
To congure the Primary and Secondary DNS server IP addresses
1. Go to System > Network > Options, enter the Primary and Secondary DNS IP ad-
dresses that you recorded above and select Apply.
To congure a Default Gateway
1. Go to Router > Static and select Edit icon for the static route.
2. Set Gateway to the Default Gateway IP address you recorded above and select OK.
Transparent mode
To switch from NAT/route mode to transparent mode
1. Go to System > Cong > Operation Mode and select Transparent.
2. Set the Management IP/Netmask to 192.168.1.99/24.
3. Set a default Gateway and select Apply.
To change the administrator password
1. Go to System > Admin > Administrators.
2. Select Change Password for the admin administrator and enter a new password.
To change the management interface
1. Go to System > Cong > Operation Mode.
2. Enter the Management IP address and netmask that you recorded above and select
Apply.
To congure the Primary and Secondary DNS server IP addresses
1. Go to System > Network > Options, enter the Primary and Secondary DNS IP ad-
dresses that you recorded above and select Apply.
Command Line Interface
1. Use the RJ-45 to DB9 serial cable to connect the FortiGate Console port to the man-
agement computer serial port.
2. Start a terminal emulation program (HyperTerminal) on the management computer. Use
these settings:
3. Baud Rate (bps) 9600, Data bits 8, Parity None, Stop bits 1, and Flow Control None.
4. At the Login: prompt, type admin and press Enter twice (no password required).
NAT/Route mode
1. ConguretheFortiGateinternalinterface.
cong system interface
edit internal
set ip <intf_ip>/<netmask_ip>
end
2. Repeattocongureeachinterface,forexample,toconguretheWAN1interface.
cong system interface
edit wan1
...
3. ConguretheprimaryandsecondaryDNSserverIPaddresses.
cong system dns
set primary <dns-server_ip>
set secondary <dns-server_ip>
end
4. Congurethedefaultgateway.
cong router static
edit 1
set gateway <gateway_ip>
end
Transparent Mode
1. ChangefromNAT/RoutemodetoTransparentmodeandconguretheManagementIP
address.
cong system settings
set opmode transparent
set manageip <mng_ip>/<netmask>
set gateway <gateway_ip>
end
2. ConguretheDNSserverIPaddress.
cong system dns
set primary <dns-server_ip>
set secondary <dns-server_ip>
end
Collecting Information
Conguring
NAT/Route mode
You would typically use NAT/Route mode when the FortiGate unit is deployed as a gateway
betweenprivateandpublicnetworks.InitsdefaultNAT/Routemodeconguration,theunit
functionsasarewall.FirewallpoliciescontrolcommunicationsthroughtheFortiGateunit.
Transparent mode
You would typically use the FortiGate unit in Transparent mode on a private network behind
anexistingrewallorbehindarouter.InitsdefaultTransparentmodeconguration,theunit
functionsasarewall.
RefertotheToolsandDocumentationCDforinformationonhowtocontroltrafc,andhowtocongureHA,antivirusprotection,FortiGuard,Webcontentltering,Spamltering,intrusion
prevention (IPS), and virtual private networking (VPN).
