Fortinet FortiGate 500D User Manual

FortiGate 500D
8
7
6
5
USB MGMT
USB
4
3
2
1
MGMT 2
MGMT 1
CONSOLE
1614
13
12
11
10
9 15
Console (RJ-45)
Optional connection to the management
computer. Provides access to the CLI
USB MGMT (USB mini-B)
USB client port for management
SFP Ports 1 - 8 (SFP)
1 Gbps small form-factor
pluggable transceiver ports
Ethernet Ports 9 - 16 (RJ-45)
Gigabit Ethernet ports for connection to your
network and the Internet
MGMT 1 & 2 (RJ-45)
Client ports for management.
Default IP address of MGMT 1
is 192.168.1.99
Power
100-240V AC, 50-60Hz, 4-2A
RPS
Optional connection for redundant power.
12V DC, 17A
USB (USB A)
USB server ports for USB key,
modem, or management functions
