Fortinet FortiGate 70D User Manual

USB MGMT (USB mini-B)
USB client port
WAN Ports 1 - 2 (RJ-45)
Gigabit Ethernet ports for
connection to the Internet
PoE Ports A - D (RJ-45)
Gigabit Ethernet ports with Power over Ethernet
(PoE) support, up to 15.4W per port
Ethernet Ports 1 - 10 (RJ-45)
Gigabit Ethernet 10-port switch for
connection to your network
Power
48V DC, 2.5A
100-240V AC, 50-60Hz adapter
Attention: Ground lug must be
connected to ground screw
USB (USB A)
USB server ports
DC+48V
USB
9
AC
D
PoE
B
7 5 3 1
WAN 1
10 8 6 4 2
WAN 2
USB
MGMT
Internet

Fortinet FortiGate 70D Specifications

General

Brand	Fortinet
Model	FortiGate 70D
Category	Firewall
Language	English
