Fortress S-Series
7.0 Scooter Control System
7.1 SCOOTER CONTROL CONSOLE
FIG.7.1
7.1.6 LIGHTS
7.1.5 INDICATORS
7.1.4 HAZARD LIGHTS
7.1.3 HORN
7.1.8 BATTERY LEVEL GAUGE
7.1.7 SPEED CONTROL
7.1.5 INDICATORS
7.1.9 50% SPEED PROFILE
FIG.7.2
7.1.1 KEY SWITCH
7.2 CHARGER SOCKET
TILLER ADJUSTER
FIG.7.3
7.1.2 CONTROL LEVER
(WIG-WAG)
