Foundation FP-68KM4 - FP-170-204-238 KM4 Unit Dimensions

Page 30 of 49
Ceiling cassette
Fan
Coil Unit
, 4
-
pipe system
Model: FP-
KM
FP-170-204-238KM4
FRESH AIR DUCT
FAN BLOWER MOTOR
MOUNTING BRACKET
PANEL COVER
TERMINAL BLOCK
WATER PURGE
HOT WATER OUTLET
HOT WATER INLET
CHILLED WATER INLET
BRANCH DUCT
AIR VENT
CHILLED WATER OUTLET
DRAINAGE
