Foundation FP-68KM4 - FP-85-102-136-170-204-238 KM4 Wiring Diagram and Legend

Page 44 of 49
Ceiling cassette
Fan
Coil Unit
, 4
-
pipe system
Model: FP-
KM
Water Cassette Wiring Diagram
PCF-09-10-12-16-18-20-PS
N
L
CV HV A1
TB
Wall Pad
A2
A2
A1
T
JP2
Blue
Black
JP3
J
P
1
JP4
Black
M
JP5
M
N
HIGH
AUX2
LOW
Red
Red
MED
Brown
JPH
Yellow/Green
Legend:
JP0----Short is master
Open is slave
JP1----Transformer
JP2----Power supply
JP3----2-way valve of Cooling
JP4----Drainage pump
JP5----Fan motor
JP6----Remote receiver
JP7----Stepping motor
JP8----Stepping motor
JP9----Stepping motor
JP10---Stepping motor
JP11---Room TEMP. sensor
JP13---Wall pad
JP14---Float switch
JPH----2-way valve of Heating
JIPH---Coil TEMP. sensor of Heating
JIPC---Coil TEMP. sensor of Cooling
AUX1---Auxiliary 1 for heat
AUX2---Auxiliary 2 for cool
JP8
JP9JP10
JP0
JP7
JIPC
JP11
JP13
JIPH
JP14
JP6
White
SM3
、4
SM1
、2
H
M
L
A
U
X
1
White
CPU
FP-85-102-136-170-204-238 KM4
