ATTACH INFANT SEAT TO GAGGLE SEAT
Adjustment:
Place child in seat with buckle clips
detached from center buckle. Top straps go
over shoulders, waist straps wrap around
child and snap into crotch strap on center
buckle.
Snap buckle clips into center buckle until
you hear and feel a click.
WARNING: Be careful to keep childs nger,
body or clothes from catching in buckle.
Slip strap adjusters L on shoulders and
on crotch strap along the belt webbing until
child is secure.
To release buckle assembly press center
button M .
See gure 4
AB20045_G3
J
H
2
K
1
G
Seat Strap routing:
Place infant seat into buggy seat. Route
female half of buckle 1 through bottom of
hole G and snap to male half of buckle 1
until you feel and hear a click, Take free
end of belt with buckle 2 and route under
buggy seat and up the back of buggy seat.
Route male half of buckle 2 through back
of hole H and through back of hole J ,
over seat and snap to female half of buckle
2 until you feel and hear a click. Pull
loose end of remaining belt K tight.
See gure 3
Figure 3
AB20045_G8
M
L
L
SECURE CHILD IN SEAT
Figure 4
4
