It is forbidden to put your hands in this area. Danger of
dragging/cutting.
Indicates that this machine is equipped with a laser pointing device (see par.
SAFETY INSTRUCTIONS FOR THE POINTING DEVICE).
Serial number / year of production
ELECTRICAL CONNECTIONS
Use 230 V 50 Hz alternate voltage equipped with a earthing conductor to supply your
machine. Ensure that the power supply corresponds to this voltage, that it is protected by a
differential and magnetothermal switch, and that the earthing system is efficient. If your
machine does not work when connected to a socket, check carefully the power supply
features.
Use an extension cable in order to connect the machine to the power supply.
EARTHING INSTRUCTIONS
If the tool does not work properly or in case of short-circuit, the earthing system provides the
current with a less resistance path and reduces the risk of electric shock. This tool has a plug
to which a supply or extension cable must be connected, which in turn must be connected to a
socket correctly installed and earthed, in conformity with local standards and regulations. Be
sure that your earthing system is in good conditions and that your plug is protected by a
differential and magnetothermal switch.
Do not modify the plug of the machine. If it does not enter the socket, get a suitable plug
installed by a qualified person. If the earthing conductor is not correctly connected the risk of
electric shock can occur. The conductor which has the green insulating jacket (with or without
a yellow line) is the earthing conductor. If you must repair or change the supply cable, do not
connect the earthing conductor to a low tension terminal.
Consult a qualified electrician or a person in charge of the maintenance if you have not
understood or you have some doubts on the earthing instructions.
Socket with earthing
system
Machine’s plug
