4
BATTERIES
The BT Series requires four (4) AA batteries. Acceptable battery types
include: Alkaline, rechargeable NiMH or LiFeS
2
(1.2 to 1.6 volts each).
DO NOT use Lithium Ion AA batteries (3V, 3.3V or 3.6V) as they will
damage the unit and VOID the FoxFury warranty.
NOTE: Mixing of new and used, or different brand batteries is not
recommended as this could lead to leakage or explosion.
BATTERY INSTALLATION AND REPLACEMENT
1. Turn the Locking Mechanism (located on the Battery Door) counter-
clockwise. Pull the Battery Door straight out, away from the Light Body.
NOTE: The Battery Door will remain attached to the Light Body.
2. Then, tilt the Light Body up so that the Battery Holder slides out.
3. Once the Battery Holder is out of the Light Body, flip the Battery Holder
over. Press the Battery Holder Release Button to open it.
3
1 2
4
*
FRONT
BACK
BATTERY
HOLDER
RELEASE
BUTTON
LOCKING
MECHANISM
USE HEX KEY
IN BATTERY
DOOR
LOCK HOLE
