Foxtronics FOXCART MARK II - AC Connector Wiring

X
Y
Z
G
HUBBELL 460P7W WIRE CONNECTIONS
(REAR VIEW OF CONNECTOR)
3 PHASE
6/4 CABLE
BLACK
WHITE
RED
GREEN
L1
L2
L3
X
Y
Z
G
L1
L2
L3
GREEN
BLACK
WHITE
SINGLE PHASE
4/3 CABLE
3448 W. Mockingbird Ln. Dallas, TX 75235 PHONE: 214/358-4425 FAX: 214/358-1519
TITLE: FOXCART AC CONNECTOR WIRING
DRAWING NO: 400-0005-033
PAGE: 1 OF 1
REV: C
DRAWN BY: SE
APPROVED BY:
DATE: 07/30/08
foxtronics
incorporated
X
Y
G
L1
L2
GREEN
BLACK
WHITE
SINGLE PHASE
4/3 CABLE (ONLY)
FIGURE 9.
HUBBELL 3100P6W WIRE CONNECTIONS
(REAR VIEW OF CONNECTOR)
