FPZ SCL K08-MS - Installation Schematics; Pressure and Vacuum Service Diagrams; Parallel and Series Configurations; List of Installation Accessories

2. INSTALLATION SKETCHES
2.1 PRESSURE SERVICE
2.2 PARALLEL PRESSURE SERVICE
2.3 SERIES PRESSURE SERVICE
2.6 LIST ACCESSORIES
2.4 VACUUM SERVICE
2.5 PARALLEL VACUUM SERVICE
Item
Denomination
Item
Denomination
1
Filter – Inline filter 7
Valve
(2)
Silencer (8)
Cooler
3
Flexible coupling
(9)
Thermometer
4
Pressure – Vacuum gauge (10)
Temperature switch
5
Safety valve
6
Non return valve
(x) IF NECESSARY
GB - 15/39
