CONNECTION AND INSTALLATION WITH XBOX ONE™ AND XBOX SERIES X/S™
ATTENTION: Before beginning the installation procedure, make sure that the video console and the Xbox One™ or Xbox
Series X/S™ controller are switched o.
ATTENTION: USB to USB-C data and charging cable not included.
To use the Formula Wheel steering wheel in Xbox One™ or Xbox Series X/S™ follow the instructions given below in the order
shown:
1. Plug the pedal cable into the “Pedals” port on the steering wheel.
2. Use the USB cable to connect the original Xbox One™ or Xbox Series X/S™ controller to the “Steering Controller” port
on the steering wheel.
3. Switch on the console.
4. Plug the steering wheel’s USB cable into the USB port on your Xbox One™ or Xbox Series X/S™ video console.
5. When installation is complete, the red LED on the steering wheel will light up and the Xbox One™ or Xbox Series X/S™
video console will assign a connection channel.
6. With the red LED on the steering wheel lit up, press the “HOME” button to access the system menu or play a game.
7. Press the “HOME” button to access the conguration menu or press the “HOME” button for 1 second to access the
shutdown menu.
CONNECTION AND INSTALLATION WITH NINTENDO SWITCH™
To use the Formula Wheel steering wheel in Nintendo Switch™ follow the instructions given below in
the order shown:
Attention. If you have not used the original “Switch PRO” controller before, please use the JoyCon to adjust the settings as
follows to enable connection via USB cable.
1) System Settings
2) Controllers and sensors
3) Pro Controller Wired Communication -> On
1. Plug the pedal cable into the “Pedals” port on the steering wheel
2. Connect the steering wheel’s USB cable to the USB port on the Nintendo Switch™ video console
3. Switch on the Nintendo Switch™ console
4. When installation is complete, the red LED on the steering wheel will light up
5. To take a screenshot, simultaneously press the “SHARE” button and the “OPTIONS” button.
CONNECTION AND INSTALLATION WITH PC
To use the Formula Wheel steering wheel with a PC follow the instructions given below in the order
shown:
1. Plug the pedal cable into the “Pedals” port on the steering wheel.
2. Plug the USB cable into the USB port on the PC.
3. When installation is complete, the red LED on the steering wheel will light up.
Connection mode:
a. PC (Xinput):
1. The default connection mode is Xinput.
2. To enter the Dinput connection mode, press and hold down the “HOME” button for 3 seconds. The red LED will ash for
3 seconds.
3. To return to the Xinput connection mode, press and hold down the “HOME” button for 3 seconds .
b. PC (Dinput):
1. Open the drivers directory.
2. Press “SETUP”.
3. Install the drivers following the instructions.
4. Connect the steering wheel to the PC.
5. Go to Start.
6. Go to Control Panel.
7. Go to Devices and Printers.
8. Right click on Devices.
9. Go to Controller Settings.
10. Go to Properties.
Steering wheel test:
• In the test interface, you can test the operation of the buttons and the steering wheel rotation separately.
• You can calibrate the steering wheel rotation in the calibration interface.
• You can test the vibration in the vibration interface
• You can test the operation of pedals and gears in the test interface
Deleting drivers:
1. Go to Start => Control Panel= > Apps and Features/Programs and Features
2. Find the name of the driver and click on “delete”
3. Download the drivers at: https://blade.es/en/producto/formula-wheel-eng/
TROUBLESHOOTING:
• If the red LED is not lit at the end of the installation procedure, reconnect the steering wheel and repeat the installation pro-
cess
• If the steering wheel does not respond, please disconnect and reconnect it, repeating all the installation steps in the order
shown
• The steering controller should be switched o during the installation process to avoid connection failure during installation
• The steering wheel has a button conguration memory, so if the buttons are congured incorrectly follow the instructions in
“RESETTING A BUTTON CONFIGURATION” or “RESTORING FACTORY SETTINGS” to clear the stored settings
