Axe-Fx Mode NONE means that we use the MFC-101 as generic MIDI controller, because the Axe-Fx III is not supported for Axe-Fx Mode.
BankSize determines how many scenes you can control per preset, here 8. De facto we use each MFC-101 bank for ONE Axe-Fx III preset, which we select directly by BANK
UP/DOWN (BankStyle = FIRST). IA Switches used for FX BYPASS or FX CHANNEL or TUNER are set to TOGGLE. An IA Switch, which we use for Tempo, is set to MOMENTARY.
With the Save Edits Switch to ON we enable us to define the status of the global IA switches for each preset and scene and to store them directly in the MFC-101 using the
EDIT/SAVE button. We program each IA switch per scene on the MFC-101 and store it. The Axe-Fx III assumes this status per scene, so it is also recommended to save the
Axe-Fx III preset after programming is complete. Thus, MFC-101 and Axe-Fx III are now always running `IN SYNC`. For this to work, IA Switch Send w/ Preset must be configured
to YES.
STEP 3: MFC-101: EDIT->MIDI
We make the following settings in the MFC-101 MIDI Menu:
EDIT -> MIDI
12.4 The MIDI Menu
EDIT -> MIDI
12.4 The MIDI Menu
12.4.0 MFC--101 Port
MIDI
12.4.10 IA Switch Program Change Settings
IA01-17 | pOF | PC#OFF
12.4.1 Axe--Fx MIDI Channel
1
12.4.11 IA Switch Custom MIDI Messages
S01 OF
12.4.4 MFC--101 MIDI Receive Channel
OFF
12.4.12 Internal Control Change Settings
IntCC 01-08 = SCENE# Ch01
12.4.5 MFC--101 Receive Program Change
OFF
IntCC 09-17 = OFF
12.4.6 MFC--101 Program Change Map
no mapping (000 = 000;…)
12.4.13 Internal Control Change ON/OFF
Values
IntCC 01 OF OFF ON 000
IntCC 02 OF OFF ON 001
IntCC 03 OF OFF ON 002
IntCC 04 OF OFF ON 003
IntCC 05 OF OFF ON 004
IntCC 06 OF OFF ON 005
IntCC 07 OF OFF ON 006
IntCC 08OF OFF ON 007
12.4.8 IA Switch Control Change (CC#) Settings
Set c1 CC# to the corresponding MIDI
function from the Axe-Fx III MIDI/Remote
menu. Use Ch01 (MIDI channel of the Axe-Fx
III).
Set c2 CC# to OFF or to the corresponding
MIDI function from the Axe-Fx III
MIDI/Remote menu, if a second function
should always be controlled with c1 CC#.
12.4.9 IA Switch Control Change ON/OFF Values
OFF 000 | ON 125 for
FX BYPASS; TUNER; FX CHANNEL A/B IA Sw.
OFF OFF | ON 125 for TAP Tempo IA Sw.
