Fram King 25 Series User Manual

44 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

Rotary Tiller

25 Series - 40", 48" & 60"

OperatOr and parts Manual

082010

FK303

Table of Contents

Questions and Answers:

V
vegajenniferAug 1, 2025
What to do if there is untilled ground behind Fram King 25 Series Lawn and Garden Equipment?
- S
  Shawn CooperAug 1, 2025
  If the ground behind the Fram King Lawn and Garden Equipment remains untilled, several factors could be at play. First, ensure that the 3-point hitch system is properly set in float. Traveling too fast can also cause this issue, so try slowing down. For very hard ground, reduce your speed and consider making two passes. Finally, check if the machine is level and adjust the screw jack on the 3-point arm and the Depth Gauge Shoes as needed.
T
trevor10Aug 8, 2025
Why won't the rotor turn on my Fram King 25 Series?
- L
  Laura BarrettAug 9, 2025
  If the rotor on your Fram King Lawn and Garden Equipment won't turn, it could be due to a few reasons. Begin by checking if the slip clutch is slipping and ensure it's engaged, or consider replacing the friction plates. Another potential cause is a slipping PTO clutch, which you can address by setting the PTO clutch according to your tractor manual. Lastly, inspect the drive chain for any breaks, and repair or replace it if necessary.
K
Katelyn MendezAug 16, 2025
Why is the seed bed uneven with my Fram King 25 Series?
- A
  Alisha LewisAug 16, 2025
  An uneven seed bed with your Fram King Lawn and Garden Equipment can result from the machine not being level. Make sure to level the machine. Also, check the Drag Shield; if it's too high, adjust it accordingly.
