FRANCE ETUVES C3030 User Manual

Name: FRANCE ETUVES C3030
Brand: FRANCE ETUVES
Rating: 4 (1 reviews)

44 pages

To Next Page

Rev 2 FRANCE-ETUVES 65/67 rue Auguste Meunier 77500 Chelles (FRANCE)

Temperature controller C3030

Original instructions

READ THIS MANUAL BEFORE SWITCHING ON THE DEVICE

Table of Contents3
Introduction5
Safety Precautions to Take When Using and Repairing the Device5
Temperature Controller Description6
Graphic Display Presentation7
Electronic Thermostat for Protection against Overheating10
Protecting Thermostat Description10
Electronic Protection Thermostat Function in TWW Mode (Automatic Reset)12
Electronic Protection Thermostat Function in TWB Mode (Manual Reset)13
TWB Mode Electronic Thermostat Reset13
Setpoint Deviation Tracking (SDT) System Working14
Overheating Protection Thermostat and SDT Settings15
Manual Regulation17
Program18
Program Structure18
Program Creation19
Step Setting19
Number of Program Iteration Setting20
Guaranteed Soak Band Settings21
Delayed Start Setting22
Program Example22
Starting a Program23
Program Pause24
Stopping the Program25
Program End25
Power Failure Controller Reaction25
Weekly Timer (Option)26
Working Principle26
Setting and Operation26
Controller Settings27
Settings Parameters Description27
Defining the Parameters29
PID Regulation29
Temperature Correction30
Temperature Coefficient (for XFE Range)33
XFE Range Working Principle33
Temperature Coefficient Function Working33
Date and Time34
RS 485 Connection34
Password35
Beep35
Heating and Fan Stop When Door Is Open36
Remote Oven Control from a37
Modbus Protocol37
Data Frame to Send to the Controller37
Controller-Returned Data Frame38
List of Available Parameters Via Modbus Communication38
France-Étuves Remote Control Software40
Troubleshooting41
General Safety Instructions41
Failures Displayed41
Electronic Thermostat Failures41
Other Failures42
Breakdowns43
