Franke FS Series User Manual

3 | Technical data - FS/FSU Franke Kaffeemaschinen AG
10 User manual FS/FSU
Electrical connection data
Type Country
FCS4055 CH, EU,
GB, USA,
CAN, JP,
CN, BR
Voltage 100–240V
Frequency 50–60Hz
Power rating 45W
Current consumption < 0.4A
Fuse 10A
Connection 1L N PE
Bottle sizes for FS60
The bottle diameter determines the number of bottles that can be used in the
Flavor Station.
Possible bottle sizes
Number of bottles 6 5 4 3 2 1
Max. bottle diameter 75 mm 78 mm 78 mm 78 mm 112
mm
136
mm
Example: If you wish to use 6 syrup bottles, then the maximum diameter the
bottles may have is only 75 mm.
Combinable bottle sizes
Depending on the bottle diameter, you can use different bottle sizes.
Number of bottles 1 2 3 4 5
Bottle diameter 85 mm 85 mm 85 mm 85 mm 85 mm
Can be combined with
Number of bottles 5 3 1 – –
Bottle diameter 75 mm 75 mm 75 mm – –
