EN
2
6
26
Replacing the fuser
The hood panel opening and closing mechanism is con-
trolled by a starter motor which is activated by a fuser.
This fuser works only on the starter motor. In case the
fuser gets damaged when the panel is closed it is be
necessary to manually unblock the panel. In this case
proceed as follows:
Remove the cover placed up on the left side.
Press the releasing lever with the screwdriver as
much as necessary to enable the manual opening of
the panel.
After having completely opened the panel remove the
metal grease filters, as explained in the part concern-
ing the filter cleaning.
The fuser is placed up on the right side. Turn the
fuser holder as indicated. Replace the fuser with one
having the same features.
Put the fuser holder and grease filters into their place
again. Make sure that the hood functions correctly. In
case the panel doesn’t work correctly it is necessary
to contact an authorized technician.
If the fuser gets damaged being the panel open, it is suf-
ficient to simply remove the grease filters and replace
the fuser.
