4
Figure-3. Configuration for Adjustment and Test of WIMAX mode
2. Diagram of connecting the S600 and the antenna
Figure-4. Diagram of connecting the module and the antenna
Table-1. Port definition of RF connectors
Port definition 1 2 3 4
S600 WiMAX Main CDMA Aux+GPS WiMAX Aux CDMA Main
Figure -5 Port definition of RF connectors
