Page 6 For technical questions, please call 1-888-866-5797. Item 70027
Record Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and
are not available individually as replacement parts.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS DOCUMENT AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List and Diagram
Parts List
Part Description Qty
1 Nose Plate 1
2 Frame 1
3 Strut 2
4 Left Axle Bracket 1
5 Right Axle Bracket 1
6 Nose Plate Extension 1
7 Axle 1
8 Wheel 2
9 Right Connected Plate 1
10 Latch 1
11 Left Connected Plate 1
12 End Cap 2
13 Small Handle 1
14 Small Handle Enforcement 2
15 Lock 1
Part Description Qty
16 Steel Plate 1
17 Handle Support Bar 1
18 Handle 1
19 Caster 2
20 Bolt M8x60 4
21 Nut M8 12
22 Washer M16x2T 4
23 Spacer 2
24 Cotter Pin 2
25 Bolt M12x100 2
26 Nut M12 2
27 Bolt M8x50 2
28 Bolt M8x45 2
29 Bolt M8x40 2
