6. To RUN another Low Power Mode
• Press the RESET button on the Freedom board
• Return to Hyperterminal window and Select another power mode
(typing 0 to 9 or A to L) and press any key to confirm
EXAMPLE of measurement for :
- CASE 0: Enter VLLS0 with POR disabled (Very Low Leakage STOP 0) NO POR
- CASE 20: Enter Compute Mode run for(i=0;i<wait_count;i++)
Preliminary
