11/2/2006 f490284
A
1
2
3
4
6
7
8
9
4
4
B
5
C
A. Inspect this area of the canister for dents.
B. DOC Area
C. DPF Area
1. Inlet Temperature Sensor
2. Marmon Fitting at Inlet from Turbocharger
3. Sensor Housing
4. DPF V-Band Mounting Clamps
5. Inlet Temperature Sensor
6. Exhaust Outlet to Diffuser
7. Outlet Temperature Sensor
8. DPF Outlet Pressure Sensor
9. DPF Intake Pressure Sensor
Fig. 2, Cummins Aftertreatment Device
Exhaust49
Recreational Vehicle Chassis Maintenance Manual, November 201549/4
