GENERAL TECHNICAL DATA
Page 5
Installation Manual Hot Deli 3/4/5/7 form 9123544 rev. 07/2015
GENERAL TECHNICAL DATA
This manual covers the Hot Deli Merchandisers in the models curved and square. The Mer-
chandisers come in 4 sizes to build-in into an existing counter. Merchandisers will also be
deliverd on an underframe.
The Merchandisers come in 3 models.
• Premium = Full service with humidification.
• Essential = Full service.
• Self-Serve = Self service.
All of the information, illustrations and specifications contained in this manual are based on
the latest product information available at the time of printing.
TECHNICAL DATA
Type HD 3 HD 4 HD 5 HD 7
Power (W) Premium 4600 4900 5100 8600
Power (W) Essential 3700 4000 4200 7700
Power (W) Self Service 3700 4000 4200 -
Fuses needed with power connection
400V, 3N~50Hz (3 phases with zero)
3x 16 A 3x 16 A 3x 16 A 3x 16 A
Fuses needed with power connection
230V, 3~50Hz (3 phases without zero)
3x 16 A 3x 16 A 3x 20 A 3x 32 A
Fuses needed with power connection
230V, 1N~50Hz (1 phase with zero)
32 A 32 A 32 A 50 A
Standard plug from factory CEE-form 5-pole 16 A 16 A 16 A 16 A
Net weight full service, humidified (kg) 157 210 240 272
Net weight full service (kg) 142 195 225 257
Net weight self service (kg) 136 188 217 -
Gross weight full service, humidified (kg) 212 275 315 355
Gross weight full service (kg) 197 260 300 340
Gross weight self service (kg) 191 253 292 -
Height (mm) 960 960 960 960
Width (mm) 1086 1419 1752 2505
Depth (mm) 1058 1058 1058 1058
Tools
• Standard set of tools.
• Metric wrenches, sockets and hex socket key wrenches.
• Multi meter and AC current clamp meter.
• Temperature tester.
• Insulation value tester (Megger).
• Field Service Grounding Kit.
