WWW.FRIJADO.COM
Service Manual TDR5/8 P TDW5/8 P form 9123911 rev. 10/2014
SERVICE MANUAL
TDR P
eco
- ROTISSERIE OVEN MODELS
TDW - WARMER MODELS
- NOTICE -
This manual is prepared for the use of trained Service Technicians
and should not be used by those not properly qualified. If you
have attended a training for this product, you may be qualified to
perform all the procedures in this manual.
This manual is not intended to be all encompassing. If you have
not attended a training for this product, you should read, in its
entirety, the repair procedure you wish to perform to determine
if you have the necessary tools, instruments and skills required to
perform the procedure. Procedures for which you do not have the
necessary tools, instruments and skills should be performed by a
trained technician.
Reproduction or other use of this Manual, without the express
written consent of Fri-Jado, is prohibited.
MODELS
TDR 5 P
eco
TDR 8 P
eco
TDW 5 P
TDW 8 P
Model TDR 5 P
eco
Model TDR 8 P
eco

Table of Contents

Questions and Answers

  • D
    Dylan GrimesAug 18, 2025
    Why does the oven temperature differs from temperature setting in my Fri-Jado Kitchen Appliances?
    • B
      Brad HodgeAug 18, 2025
      If the Fri-Jado Kitchen Appliance oven temperature differs from the temperature setting, it could be due to several reasons: * Incorrect line voltage. * Malfunction of the safety thermostat. * Inoperative blower motor (check turning direction). * Inoperative electronic control. * Malfunction of the PT 1000 sensor. * The PT 1000 sensor is not in the right place. * Dirty fanguard or fanblade.
  • A
    awallaceAug 20, 2025
    Why Fri-Jado Kitchen Appliances oven temperature does not reach desired temperature?
    • W
      William BarnesAug 20, 2025
      If the Fri-Jado Kitchen Appliance oven temperature isn't reaching the desired level, it could be caused by: * A malfunctioning safety thermostat. * An inoperative contactor. * A malfunctioning PT 1000 sensor or its incorrect placement. * An inoperative electronic control. * Inoperative heater(s). * Incorrect line voltage.
  • J
    James OdonnellAug 23, 2025
    Why does the main fuse or breaker blows on my Fri-Jado TDR 5 P eco?
    • H
      hubbardedwardAug 23, 2025
      If the main fuse or breaker blows in your Fri-Jado Kitchen Appliance, it could be due to: * Incorrect wiring. * A shorted heating element, drive motor, blower, or contactor. * Shorted wiring.
  • J
    Jennifer AdamsAug 26, 2025
    Why infrared Halogen lamps do not work in Fri-Jado TDR 5 P eco Kitchen Appliances?
    • B
      Bryan DicksonAug 26, 2025
      If the infrared Halogen lamps in your Fri-Jado Kitchen Appliance do not work, the possible causes are: * Contactor inoperative. * Broken lamp(s). * Broken lamp holder. * Loose wiring.
  • K
    Kim ClarkAug 28, 2025
    What causes the drive motor not to run during cooking cycle in Fri-Jado Kitchen Appliances?
    • T
      Tyler FranklinAug 28, 2025
      If the drive motor in your Fri-Jado Kitchen Appliance does not run during the cooking cycle, it could be due to: * An inoperative main fuse on L1. * Capacitor malfunction. * Motor malfunction. * Door switch malfunction. * Power and I/O board malfunction (check relay X12). * Loose wiring.
  • B
    brianadkinsAug 30, 2025
    Why all heating elements are out in my Fri-Jado TDR 5 P eco Kitchen Appliances?
    • C
      Christopher BeasleyAug 30, 2025
      If all heating elements are out, but the halogen lamps and blower operate while the oven cavity is below the set temperature in your Fri-Jado Kitchen Appliance, it could be due to: * Malfunction of the safety thermostat. * Inoperative contactor. * Power and I/O board malfunction. * Loose wiring.
  • A
    Antonio RomanSep 2, 2025
    Why blower motor does not run in Fri-Jado TDR 5 P eco Kitchen Appliances?
    • S
      sharon53Sep 2, 2025
      If the blower motor in your Fri-Jado Kitchen Appliance does not run, consider the following possible causes: * Capacitor malfunction. * Motor inoperative. * Power and I/O board malfunction (check relay X6). * Loose wiring.
  • M
    michaelcastilloSep 4, 2025
    Why does drive motor stops and runs again after a certain period in Fri-Jado TDR 5 P eco Kitchen Appliances?
    • D
      David HarperSep 4, 2025
      If the drive motor in your Fri-Jado Kitchen Appliance stops and runs again after a certain period, it is likely due to thermal protection being activated at 105°C. The motor will restart once the temperature drops below 105°C.
  • C
    Chad HughesSep 7, 2025
    Why does blower motor stops and runs again after a certain period in Fri-Jado TDR 5 P eco Kitchen Appliances?
    • S
      Sheila BuchananSep 7, 2025
      If the blower motor in your Fri-Jado Kitchen Appliance stops and runs again after a certain period, it's because thermal protection has been activated at 140°C. It will resume running once the temperature falls below 140°C.
  • C
    Catherine FloresSep 9, 2025
    Why all beep functions do not function anymore in Fri-Jado Kitchen Appliances?
    • D
      David HamiltonSep 9, 2025
      If all beep functions do not function anymore on your Fri-Jado Kitchen Appliance, it could be due to: * Obsolete software (older than V1.03.06). Load the latest software. If no software is available unplug the unit for 5 seconds and plug in again. Now the beep signal will work again for 49 days. * All sounds in the parameter list are disabled (switched off).

Summary

Programming Instructions

Operating Panel and Controls

Overview of operating panel keys and display functions for ovens and warmers.

Manager Menu Operations

Guide to accessing and using the Manager Menu for programming recipes and parameters.

Parameter Configuration and USB Functions

Removal and Replacement of Parts

External Panels and Covers

Control and Display Components

Internal Electrical and Motor Components

Electrical Tests and Service Procedures

Component Testing and Error Codes

Guides for testing components and understanding error codes displayed on the unit.

Troubleshooting Common Issues

General Troubleshooting for Rotisseries

Common problems and solutions for TDR 5 and 8 rotisseries.

Error 55 Explanation

Detailed explanation and causes for Error 55 related to heating defects.

Electrical Diagrams

TDR 5 and 8 P Schematics

TDW 5 and 8 Schematics

Fri-Jado TDR 5 P eco Specifications

General IconGeneral
Power2.9 kW
Frequency50/60 Hz
MaterialStainless steel
Capacity5 Chickens
Voltage230 V
